Socket Insert Sq. | mm(inch) | 19(3/4) |
---|---|---|
Capacity Bolt Diameter | mm(inch) | 20(3/4) |
Recommended Torque Range | Nm | 150-650 |
Length w/o Socket | mm(inch) | 241(9-1/2) |
Weight w/o Socket | kg | 4.2(9.2) |
Free Rotation speed | r.p.m. | 4,500 |
Air Consumption | m3(Nomal)/min. (c.f.m.) | 0.47(16.7) |
Noise level | dB(A) | 93 |
Hose Inlet Bushing | - | Rc1/4 |
Applicable Compressor | kW | 3.75 |
Hose Inside Diameter | mm(inch) | 9.5(3/8) |
